    The SMZ-140 line of stereomicroscopes combines rugged design with quality optics to provide a durable microscope for a wide range of measurement and inspection applications. The Greenough optical system provides a continuous zoom up to a maximum of 180X allowing for easy sample scanning and positioning before zooming down for more detailed views. The SMZ-140 stereomicroscope provides a  zoom ratio of 1:4 and a standard working distance of 80 mm is perfect for most applications, however, the wide range of accessories including additional eyepieces, auxiliary lenses, and more, allow for a high level of customization for your microscope.

    The compact size of the SMZ-140 stereomicroscopes further increases their versatility; multiple microscopes can fit into a small bench space or the entire microscope can be integrated into other machines or instrumentation. The all metal body and durable Greenough optics mean that the SMZ-140 stereomicroscope will provide reliable performance for years to come. With three optical carrier options, numerous stands, boom arms, and other accessories, as well as the complete line of Moticam microscopy cameras, SMZ-140 stereomicroscope provides a durable, high quality inspection, measurement, and documentation work station.

    • 45º inclined binocular head, rotates 360º, with diopter adjustment
    • Widefield eyepieces WF10X/20mm
    • Zoom ratio 4:1; total standard magnification 10X – 40X
    • Click stops at 10X, 20X, 30X and 40X
    • Working distance 80mm
    • Heavy-duty rack & pinion focusing block with slip clutch
    • Pole stand with incident and transmitted Halogen illumination with intensity control and separate on/off switch
    • Top light 12V/15W and bottom light 12V/10W Halogen
    • Supplied standard with 80mm frosted glass, black and white stage plates
