Moticam (CMOS)

Home > Products > Microscope Cameras > Moticam (CMOS)

Moticam series, a digital camera for microscope, is a digital microscopy camera that captures the perfect image through the MI Devices interface. Transfer the image to the Motic Images Plus application software and you are free to take measurements, make annotations, reports, comparisons and much more. Moticam also gives you the luxury of connecting the camera to TV monitor, projector and/or computer to easily turn your images into knowledge!

Moticam's "all-in-one-box" is packaged with camera, accessories and Motic Image Plus 2.0, that allows immediate access to examine the full functionality of the imaging camera viewing specimens, capturing image and image sharing.




    Moticam 1

    Home > Products > Microscope Cameras > Moticam (CMOS)



    The next generation Moticam


    Connect the camera and start interacting


    Welcome to the future of digital microscopy.





    Easy to Install


    Motic's unique "All In One Box" assures

    each user that this camera can fit almost any microscope.




    Increase Interaction


    Connect the camera to TV monitor,

    Projector and/or computer to

    easily turn your images into knowledge!

    High resolution streaming Wi-Fi camera.







    Customized Software


    Motic Image Plus provides all tools you need

    to quantify measure, annotate, teach, learn

    and much more. Software comes with

    unlimited updates.




    Moticam 1 - 10 Specification Details
    1 1SP 2 3 5 10
    Sensor
    Type CMOS CMOS CMOS CMOS CMOS CMOS

    Optical

    Calculation

    1/4" 1/3" 1/3" 1/2" 1/2.5" 1/2.3
    Features

    Live

    resolution

    800 X 600 pixels 1.3 MP 2.0 MP 3.0 MP 5.0 MP 10.0 MP

    Focusable

    Lens

    8mm 12mm 12mm 16mm 12mm 12mm
    Output Mini USB Mini USB Mini USB Mini USB Mini USB Mini USB


    Accessories Included



    Attachable C-mount camera



    A Focusable coated glass lens



    Two adjustable size eyepiece adapters



    A 4-dot calibration slide



    The macro viewing tube



    All cables and power supplies



    Motic Image Plus
